Large Mobile Hydraulic Cylinder Series

: ~~No price~~

商品说明

Product overview

Compact Design

High Processing Capacity

One-Time Unloading Mud

UltraFast Cloth Wash

Autonomous Operation

Lower Operating and Maintenance Costs

Low Moisture Content

商品参数

Models	Number of Chambers	Plate Specifications(mm)	Area(m²)	Chamber Volume (m³)	InstalledPower (KW)	Dimensions(mm)			Net Weight(t)
						L	W	H
XZB-1536 36 1500X1500	36	1500X1500	131.04	2.293	17.2	8377	2600	2650	36
XZB-1540 40 1500X1500	40	1500X1500	145.6	2.548	17.2	8953	2600	2650	37
XZB-1546 46 1500X1500	46	1500X1500	167.44	2.93	17.2	9817	2600	2650	39
XZB-1550 50 1500X1500	50	1500X1500	182	3.185	17.2	10393	2600	2650	40
XZB-1556	56	1500X1500	203.84	3.567	17.2	11257	2600	2650	42
XZB-1560	60	1500X1500	218.4	3.822	17.2	11833	2600	2650	44
